Cylinder Honing.
Precision bore finishing to OEM (Original Equipment Manufacturer) tolerance. 50–900 mm internal diameter, lengths to 16 m open cylinder, ±2 µm. KEZAD, Abu Dhabi.
The bore decides how long the seal lasts.
A hydraulic cylinder can be rebuilt with a new seal kit and back-pressured to spec — and still fail within weeks. When the bore is scored, oval, or tapered, the seal degrades from first stroke. The honing operation is where that failure is prevented or guaranteed.
Santoo's honing machine handles 50–900 mm internal diameter, lengths to 8 m on closed cylinders and 16 m on open cylinders in a single pass. Automatic taper correction is integrated. Every bore is measured pre- and post-operation. Nothing is finished by feel. Dimensional records are issued with the cylinder at collection — every measurement traceable to the work order and the technician who took it.
Specification.
| Internal diameter range | 50 mm – 900 mm |
| Max bore length, closed cylinder | 8,000 mm |
| Max bore length, open cylinder | 16,000 mm |
| Dimensional tolerance | ± 2 µm |
| Auto taper correction | Integrated |
| Process logging | Digital, per work order |
| Measurement | Pre- and post-operation, recorded |
| Materials | Steel, cast iron, ductile iron |
Where this service runs.
Hydraulic press cylinders, crane and rigging equipment, offshore deck machinery, mobile plant, earthmoving equipment, cement and aggregate processing, and marine steering cylinders across the GCC.
Common questions.
What bore diameter range can you hone?
50 mm to 900 mm internal diameter — covering the full range of GCC industrial and heavy-plant hydraulic cylinders.
What dimensional tolerance does the process achieve?
±2 µm. Automatic taper correction integrated. Every bore measured pre- and post-operation, results logged against the work order.
What is the maximum cylinder length?
8,000 mm closed, 16,000 mm open cylinder in a single pass.
What documentation is issued?
Pre- and post-honing dimensional records traceable to the work order and technician. Issued at collection with the cylinder.
